Method

Local Adaptive Multi-Cost Dense Stereo-Matching [LAMC-DSΜ]


Submitted on 22 Mar. 2013 11:33 by
Christos Stentoumis (NTUA)

Running time:10.8 min
Environment:2 cores @ 2.5 Ghz (Matlab)

Method Description:
This is a local stereo method.The match­ing frame­work consists of a combination of robust cost mea­sures, extracted via li­near­ly expanded cross skeleton support regions and set within a coarse-to-fine strategy.
Parameters:
census transformation: [m,n]= [11,9]
λc=45,
λADc=5,
λADg=18,
Lmax=31,
τmax=24,
Latex Bibtex:
@inproceedings{Stentoumis2013,
author = {Stentoumis, Christos and Grammatikopoulos, Lazaros and Kalisperakis, Ilias and Petsa, Elli and Karras, George},
booktitle = {ISPRS},
doi = {10.5194/isprsarchives-XL-5-W1-219-2013},
keywords = {correlation,matching,point cloud,reconstruction,surface},
pages = {XL--5/W1, 219--226},
title = {{A local adaptive approach for dense stereo matching in architectural scene reconstruction}},
url = {http://www.int-arch-photogramm-remote-sens-spatial-inf-sci.net/XL-5-W1/219/2013/},
volume = {XL},
year = {2013}
}

Detailed Results

This page provides detailed results for the method(s) selected. For each of the first 20 test images, the number of erroneous pixels at all thresholds is depicted in the table. Underneath, the left input image, the disparity / end-point error map and the estimated (and interpolated) disparity / optical flow map are shown. The error map scales linearly between 0 (black) and >=5 (white) pixels error. Red denotes all occluded pixels, falling outside the image boundaries. The false color map is scaled to the largest ground truth disparity / flow value.

Test Set Average

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.55 % 15.31 % 2.1 px 2.7 px
3 pixels 9.82 % 11.49 % 2.1 px 2.7 px
4 pixels 8.06 % 9.63 % 2.1 px 2.7 px
5 pixels 7.00 % 8.49 % 2.1 px 2.7 px
This table as LaTeX

Reflective Regions

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 36.41 % 39.77 % 5.1 px 8.0 px
3 pixels 29.18 % 32.73 % 5.1 px 8.0 px
4 pixels 24.72 % 28.38 % 5.1 px 8.0 px
5 pixels 21.55 % 25.28 % 5.1 px 8.0 px
This table as LaTeX

Test Image 0

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 10.28 % 12.35 % 1.1 px 1.8 px
3 pixels 6.36 % 8.30 % 1.1 px 1.8 px
4 pixels 4.72 % 6.44 % 1.1 px 1.8 px
5 pixels 3.55 % 5.18 % 1.1 px 1.8 px
This table as LaTeX





Test Image 1

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 12.62 % 15.78 % 1.4 px 1.8 px
3 pixels 8.88 % 11.81 % 1.4 px 1.8 px
4 pixels 7.31 % 9.83 % 1.4 px 1.8 px
5 pixels 6.23 % 8.27 % 1.4 px 1.8 px
This table as LaTeX





Test Image 2

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 10.63 % 12.21 % 1.0 px 1.6 px
3 pixels 6.47 % 8.09 % 1.0 px 1.6 px
4 pixels 4.36 % 5.95 % 1.0 px 1.6 px
5 pixels 3.45 % 4.95 % 1.0 px 1.6 px
This table as LaTeX





Test Image 3

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 21.02 % 22.94 % 2.1 px 3.2 px
3 pixels 14.57 % 16.21 % 2.1 px 3.2 px
4 pixels 11.04 % 12.43 % 2.1 px 3.2 px
5 pixels 8.97 % 10.18 % 2.1 px 3.2 px
This table as LaTeX





Test Image 4

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 10.39 % 12.43 % 1.0 px 1.5 px
3 pixels 6.16 % 8.13 % 1.0 px 1.5 px
4 pixels 4.53 % 6.23 % 1.0 px 1.5 px
5 pixels 3.36 % 4.79 % 1.0 px 1.5 px
This table as LaTeX





Test Image 5

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 3.24 % 4.69 % 0.6 px 0.9 px
3 pixels 2.22 % 3.52 % 0.6 px 0.9 px
4 pixels 1.82 % 2.99 % 0.6 px 0.9 px
5 pixels 1.54 % 2.59 % 0.6 px 0.9 px
This table as LaTeX





Test Image 6

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 28.13 % 30.10 % 5.0 px 6.0 px
3 pixels 23.01 % 25.09 % 5.0 px 6.0 px
4 pixels 20.65 % 22.78 % 5.0 px 6.0 px
5 pixels 19.36 % 21.51 % 5.0 px 6.0 px
This table as LaTeX





Test Image 7

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 25.57 % 27.37 % 4.9 px 5.9 px
3 pixels 19.90 % 21.75 % 4.9 px 5.9 px
4 pixels 16.95 % 18.75 % 4.9 px 5.9 px
5 pixels 15.51 % 17.26 % 4.9 px 5.9 px
This table as LaTeX





Test Image 8

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 2.94 % 4.66 % 0.6 px 1.1 px
3 pixels 1.83 % 3.43 % 0.6 px 1.1 px
4 pixels 1.31 % 2.82 % 0.6 px 1.1 px
5 pixels 1.09 % 2.56 % 0.6 px 1.1 px
This table as LaTeX





Test Image 9

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 23.42 % 25.28 % 2.6 px 3.7 px
3 pixels 14.86 % 16.92 % 2.6 px 3.7 px
4 pixels 11.30 % 13.28 % 2.6 px 3.7 px
5 pixels 9.40 % 11.36 % 2.6 px 3.7 px
This table as LaTeX





Test Image 10

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 11.19 % 12.73 % 1.4 px 1.7 px
3 pixels 6.70 % 8.04 % 1.4 px 1.7 px
4 pixels 5.14 % 6.37 % 1.4 px 1.7 px
5 pixels 4.26 % 5.40 % 1.4 px 1.7 px
This table as LaTeX





Test Image 11

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 20.05 % 22.93 % 2.1 px 2.8 px
3 pixels 12.73 % 15.72 % 2.1 px 2.8 px
4 pixels 8.97 % 11.85 % 2.1 px 2.8 px
5 pixels 6.95 % 9.60 % 2.1 px 2.8 px
This table as LaTeX





Test Image 12

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 16.51 % 18.51 % 3.5 px 4.7 px
3 pixels 12.81 % 14.72 % 3.5 px 4.7 px
4 pixels 10.68 % 12.45 % 3.5 px 4.7 px
5 pixels 9.60 % 11.21 % 3.5 px 4.7 px
This table as LaTeX





Test Image 13

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 24.74 % 25.78 % 4.8 px 5.2 px
3 pixels 19.50 % 20.54 % 4.8 px 5.2 px
4 pixels 17.27 % 18.30 % 4.8 px 5.2 px
5 pixels 15.97 % 17.01 % 4.8 px 5.2 px
This table as LaTeX





Test Image 14

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.42 % 15.04 % 1.7 px 2.1 px
3 pixels 8.85 % 10.43 % 1.7 px 2.1 px
4 pixels 7.15 % 8.59 % 1.7 px 2.1 px
5 pixels 6.31 % 7.61 % 1.7 px 2.1 px
This table as LaTeX





Test Image 15

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 16.28 % 17.98 % 1.6 px 2.0 px
3 pixels 11.82 % 13.15 % 1.6 px 2.0 px
4 pixels 9.13 % 10.30 % 1.6 px 2.0 px
5 pixels 7.42 % 8.52 % 1.6 px 2.0 px
This table as LaTeX





Test Image 16

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 6.58 % 7.94 % 1.0 px 1.4 px
3 pixels 4.36 % 5.69 % 1.0 px 1.4 px
4 pixels 3.41 % 4.73 % 1.0 px 1.4 px
5 pixels 2.88 % 4.19 % 1.0 px 1.4 px
This table as LaTeX





Test Image 17

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 16.65 % 17.94 % 3.5 px 3.8 px
3 pixels 14.14 % 15.13 % 3.5 px 3.8 px
4 pixels 12.78 % 13.51 % 3.5 px 3.8 px
5 pixels 11.63 % 12.23 % 3.5 px 3.8 px
This table as LaTeX





Test Image 18

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 11.08 % 12.12 % 1.9 px 2.1 px
3 pixels 8.99 % 9.96 % 1.9 px 2.1 px
4 pixels 7.49 % 8.41 % 1.9 px 2.1 px
5 pixels 6.30 % 7.20 % 1.9 px 2.1 px
This table as LaTeX





Test Image 19

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 6.92 % 9.10 % 1.3 px 1.9 px
3 pixels 4.39 % 6.24 % 1.3 px 1.9 px
4 pixels 3.55 % 5.23 % 1.3 px 1.9 px
5 pixels 3.04 % 4.68 % 1.3 px 1.9 px
This table as LaTeX
