Method

Cross-Based Local Stereo Matching [CrossCensus]


Submitted on 3 Jul. 2015 16:43 by
Duc Nguyen (Vrije Universiteit Brussel,)

Running time:30 s
Environment:1 core @ 2.5 Ghz (C/C++)

Method Description:
Cross-based shape adaptive cost aggregation with
census matching cost
Parameters:
L = 7;
\tau = 20;
Census window = 9x7;
Latex Bibtex:
@ARTICLE{4811952,
author={Ke Zhang and Jiangbo Lu and Lafruit, G.},
journal={Circuits and Systems for Video
Technology, IEEE Transactions on},
title={Cross-Based Local Stereo Matching Using
Orthogonal Integral Images},
year={2009},
month={July},
volume={19},
number={7},
pages={1073-1079},
}

Detailed Results

This page provides detailed results for the method(s) selected. For each of the first 20 test images, the number of erroneous pixels at all thresholds is depicted in the table. Underneath, the left input image, the disparity / end-point error map and the estimated (and interpolated) disparity / optical flow map are shown. The error map scales linearly between 0 (black) and >=5 (white) pixels error. Red denotes all occluded pixels, falling outside the image boundaries. The false color map is scaled to the largest ground truth disparity / flow value.

Test Set Average

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.77 % 15.29 % 2.3 px 2.7 px
3 pixels 9.46 % 10.86 % 2.3 px 2.7 px
4 pixels 7.71 % 8.98 % 2.3 px 2.7 px
5 pixels 6.67 % 7.84 % 2.3 px 2.7 px
This table as LaTeX

Reflective Regions

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 43.16 % 45.82 % 8.0 px 10.1 px
3 pixels 35.97 % 38.80 % 8.0 px 10.1 px
4 pixels 31.35 % 34.22 % 8.0 px 10.1 px
5 pixels 27.95 % 30.86 % 8.0 px 10.1 px
This table as LaTeX

Test Image 0

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 12.21 % 14.30 % 2.0 px 2.5 px
3 pixels 8.63 % 10.55 % 2.0 px 2.5 px
4 pixels 7.43 % 9.16 % 2.0 px 2.5 px
5 pixels 6.51 % 8.03 % 2.0 px 2.5 px
This table as LaTeX





Test Image 1

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 10.03 % 13.03 % 1.3 px 1.6 px
3 pixels 6.30 % 8.89 % 1.3 px 1.6 px
4 pixels 4.72 % 6.81 % 1.3 px 1.6 px
5 pixels 3.75 % 5.41 % 1.3 px 1.6 px
This table as LaTeX





Test Image 2

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 17.38 % 18.88 % 2.3 px 2.8 px
3 pixels 13.60 % 15.05 % 2.3 px 2.8 px
4 pixels 11.77 % 13.11 % 2.3 px 2.8 px
5 pixels 10.38 % 11.61 % 2.3 px 2.8 px
This table as LaTeX





Test Image 3

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 15.68 % 17.84 % 1.6 px 2.1 px
3 pixels 8.67 % 10.88 % 1.6 px 2.1 px
4 pixels 5.83 % 7.92 % 1.6 px 2.1 px
5 pixels 4.28 % 6.21 % 1.6 px 2.1 px
This table as LaTeX





Test Image 4

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 12.60 % 14.07 % 2.4 px 2.6 px
3 pixels 7.77 % 8.47 % 2.4 px 2.6 px
4 pixels 6.02 % 6.73 % 2.4 px 2.6 px
5 pixels 5.07 % 5.77 % 2.4 px 2.6 px
This table as LaTeX





Test Image 5

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 5.99 % 7.03 % 1.1 px 1.2 px
3 pixels 2.96 % 3.76 % 1.1 px 1.2 px
4 pixels 2.16 % 2.88 % 1.1 px 1.2 px
5 pixels 1.82 % 2.50 % 1.1 px 1.2 px
This table as LaTeX





Test Image 6

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 19.93 % 22.05 % 2.4 px 3.4 px
3 pixels 13.66 % 15.77 % 2.4 px 3.4 px
4 pixels 10.96 % 13.12 % 2.4 px 3.4 px
5 pixels 9.33 % 11.46 % 2.4 px 3.4 px
This table as LaTeX





Test Image 7

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 21.95 % 23.84 % 3.5 px 4.4 px
3 pixels 14.53 % 16.51 % 3.5 px 4.4 px
4 pixels 11.62 % 13.48 % 3.5 px 4.4 px
5 pixels 9.87 % 11.43 % 3.5 px 4.4 px
This table as LaTeX





Test Image 8

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 7.23 % 8.90 % 1.5 px 2.0 px
3 pixels 4.83 % 6.36 % 1.5 px 2.0 px
4 pixels 4.14 % 5.59 % 1.5 px 2.0 px
5 pixels 3.80 % 5.23 % 1.5 px 2.0 px
This table as LaTeX





Test Image 9

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 22.71 % 24.62 % 3.9 px 4.8 px
3 pixels 18.23 % 20.25 % 3.9 px 4.8 px
4 pixels 15.73 % 17.81 % 3.9 px 4.8 px
5 pixels 13.88 % 16.01 % 3.9 px 4.8 px
This table as LaTeX





Test Image 10

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 8.67 % 9.96 % 1.3 px 1.6 px
3 pixels 5.01 % 6.11 % 1.3 px 1.6 px
4 pixels 3.79 % 4.78 % 1.3 px 1.6 px
5 pixels 3.23 % 4.09 % 1.3 px 1.6 px
This table as LaTeX





Test Image 11

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 22.34 % 25.14 % 3.0 px 4.1 px
3 pixels 15.57 % 18.54 % 3.0 px 4.1 px
4 pixels 12.45 % 15.41 % 3.0 px 4.1 px
5 pixels 10.58 % 13.44 % 3.0 px 4.1 px
This table as LaTeX





Test Image 12

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 16.66 % 18.10 % 3.2 px 3.5 px
3 pixels 12.86 % 14.11 % 3.2 px 3.5 px
4 pixels 10.97 % 12.01 % 3.2 px 3.5 px
5 pixels 9.88 % 10.76 % 3.2 px 3.5 px
This table as LaTeX





Test Image 13

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 16.37 % 17.38 % 4.4 px 5.1 px
3 pixels 11.47 % 12.37 % 4.4 px 5.1 px
4 pixels 9.75 % 10.64 % 4.4 px 5.1 px
5 pixels 8.78 % 9.66 % 4.4 px 5.1 px
This table as LaTeX





Test Image 14

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 14.82 % 16.04 % 3.2 px 3.4 px
3 pixels 10.22 % 11.26 % 3.2 px 3.4 px
4 pixels 8.51 % 9.42 % 3.2 px 3.4 px
5 pixels 7.71 % 8.59 % 3.2 px 3.4 px
This table as LaTeX





Test Image 15

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 16.40 % 16.86 % 2.1 px 2.2 px
3 pixels 10.79 % 10.87 % 2.1 px 2.2 px
4 pixels 8.42 % 8.47 % 2.1 px 2.2 px
5 pixels 7.53 % 7.61 % 2.1 px 2.2 px
This table as LaTeX





Test Image 16

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 8.02 % 8.85 % 1.3 px 1.5 px
3 pixels 4.24 % 4.96 % 1.3 px 1.5 px
4 pixels 2.89 % 3.58 % 1.3 px 1.5 px
5 pixels 2.25 % 2.93 % 1.3 px 1.5 px
This table as LaTeX





Test Image 17

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 11.83 % 13.25 % 1.6 px 1.9 px
3 pixels 9.06 % 10.32 % 1.6 px 1.9 px
4 pixels 7.75 % 8.69 % 1.6 px 1.9 px
5 pixels 6.39 % 7.11 % 1.6 px 1.9 px
This table as LaTeX





Test Image 18

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.17 % 14.14 % 1.8 px 2.0 px
3 pixels 9.67 % 10.61 % 1.8 px 2.0 px
4 pixels 8.28 % 9.09 % 1.8 px 2.0 px
5 pixels 7.35 % 8.05 % 1.8 px 2.0 px
This table as LaTeX





Test Image 19

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 7.37 % 8.25 % 1.3 px 1.3 px
3 pixels 4.30 % 4.72 % 1.3 px 1.3 px
4 pixels 3.44 % 3.68 % 1.3 px 1.3 px
5 pixels 3.07 % 3.25 % 1.3 px 1.3 px
This table as LaTeX
