OpenCV Block Matching [OCV-BM] with post-processing [OCV-BM-post]
http://opencv.willowgarage.com/wiki/

Submitted on 6 Mar. 2013 22:03 by
donglai wei (mit)

Running time:0.1 s
Environment:1 core @ 2.5 Ghz (C/C++)

Method Description:
Computes a disparity map using the OpenCV block
matching algorithm, which is an implementation of Kurt Konolige's Small Vision System algorithm.
Parameters:
pre_filter_size 41
pre_filter_cap 31
sad_window_size 9
number_of_disparities 128
texture_threshold 20
uniqueness_ratio 10
speckleWindowSize 100
speckleRange 32
Latex Bibtex:
@article{Bradski00,
author = {Bradski, G.},
journal = {Dr. Dobb's Journal of Software Tools},
title = {The OpenCV Library},
year = {2000}
}

Detailed Results

This page provides detailed results for the method(s) selected. For each of the first 20 test images, the number of erroneous pixels at all thresholds is depicted in the table. Underneath, the left input image, the disparity / end-point error map and the estimated (and interpolated) disparity / optical flow map are shown. The error map scales linearly between 0 (black) and >=5 (white) pixels error. Red denotes all occluded pixels, falling outside the image boundaries. The false color map is scaled to the largest ground truth disparity / flow value.

Test Set Average

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 17.21 % 18.74 % 2.1 px 2.3 px
3 pixels 12.28 % 13.76 % 2.1 px 2.3 px
4 pixels 9.70 % 11.12 % 2.1 px 2.3 px
5 pixels 8.07 % 9.43 % 2.1 px 2.3 px
This table as LaTeX

Reflective Regions

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 43.45 % 46.13 % 8.6 px 9.3 px
3 pixels 37.03 % 39.85 % 8.6 px 9.3 px
4 pixels 32.83 % 35.71 % 8.6 px 9.3 px
5 pixels 29.55 % 32.49 % 8.6 px 9.3 px
This table as LaTeX

Test Image 0

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 14.46 % 16.37 % 1.4 px 1.6 px
3 pixels 9.53 % 11.48 % 1.4 px 1.6 px
4 pixels 7.71 % 9.66 % 1.4 px 1.6 px
5 pixels 6.13 % 8.08 % 1.4 px 1.6 px
This table as LaTeX





Test Image 1

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 14.70 % 17.34 % 1.7 px 1.9 px
3 pixels 9.91 % 12.45 % 1.7 px 1.9 px
4 pixels 8.20 % 10.44 % 1.7 px 1.9 px
5 pixels 7.12 % 9.12 % 1.7 px 1.9 px
This table as LaTeX





Test Image 2

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 22.66 % 24.09 % 2.2 px 2.3 px
3 pixels 18.02 % 19.53 % 2.2 px 2.3 px
4 pixels 14.68 % 16.25 % 2.2 px 2.3 px
5 pixels 12.22 % 13.83 % 2.2 px 2.3 px
This table as LaTeX





Test Image 3

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.42 % 15.80 % 1.3 px 1.7 px
3 pixels 8.25 % 10.77 % 1.3 px 1.7 px
4 pixels 5.79 % 8.39 % 1.3 px 1.7 px
5 pixels 3.92 % 6.57 % 1.3 px 1.7 px
This table as LaTeX





Test Image 4

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 10.20 % 11.59 % 1.1 px 1.4 px
3 pixels 5.09 % 6.42 % 1.1 px 1.4 px
4 pixels 2.93 % 4.21 % 1.1 px 1.4 px
5 pixels 2.12 % 3.32 % 1.1 px 1.4 px
This table as LaTeX





Test Image 5

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 6.29 % 6.74 % 0.9 px 0.9 px
3 pixels 3.88 % 4.23 % 0.9 px 0.9 px
4 pixels 2.85 % 3.16 % 0.9 px 0.9 px
5 pixels 2.32 % 2.63 % 0.9 px 0.9 px
This table as LaTeX





Test Image 6

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 22.15 % 24.30 % 3.1 px 3.3 px
3 pixels 18.24 % 20.47 % 3.1 px 3.3 px
4 pixels 15.44 % 17.74 % 3.1 px 3.3 px
5 pixels 13.57 % 15.92 % 3.1 px 3.3 px
This table as LaTeX





Test Image 7

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 28.75 % 30.52 % 3.3 px 3.8 px
3 pixels 20.67 % 22.64 % 3.3 px 3.8 px
4 pixels 14.12 % 16.25 % 3.3 px 3.8 px
5 pixels 11.54 % 13.74 % 3.3 px 3.8 px
This table as LaTeX





Test Image 8

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 8.11 % 8.75 % 1.1 px 1.1 px
3 pixels 5.62 % 6.07 % 1.1 px 1.1 px
4 pixels 4.20 % 4.60 % 1.1 px 1.1 px
5 pixels 3.47 % 3.86 % 1.1 px 1.1 px
This table as LaTeX





Test Image 9

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 22.95 % 24.85 % 2.4 px 2.9 px
3 pixels 16.68 % 18.74 % 2.4 px 2.9 px
4 pixels 13.53 % 15.67 % 2.4 px 2.9 px
5 pixels 11.50 % 13.68 % 2.4 px 2.9 px
This table as LaTeX





Test Image 10

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 14.76 % 15.95 % 1.2 px 1.3 px
3 pixels 8.05 % 9.28 % 1.2 px 1.3 px
4 pixels 5.04 % 6.24 % 1.2 px 1.3 px
5 pixels 3.74 % 4.91 % 1.2 px 1.3 px
This table as LaTeX





Test Image 11

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 31.53 % 33.97 % 3.3 px 3.5 px
3 pixels 22.78 % 25.50 % 3.3 px 3.5 px
4 pixels 17.63 % 20.49 % 3.3 px 3.5 px
5 pixels 14.80 % 17.73 % 3.3 px 3.5 px
This table as LaTeX





Test Image 12

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.62 % 15.81 % 2.1 px 2.5 px
3 pixels 10.14 % 12.37 % 2.1 px 2.5 px
4 pixels 8.45 % 10.66 % 2.1 px 2.5 px
5 pixels 7.32 % 9.49 % 2.1 px 2.5 px
This table as LaTeX





Test Image 13

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 24.89 % 25.90 % 2.7 px 3.0 px
3 pixels 16.71 % 17.64 % 2.7 px 3.0 px
4 pixels 13.11 % 14.01 % 2.7 px 3.0 px
5 pixels 10.80 % 11.71 % 2.7 px 3.0 px
This table as LaTeX





Test Image 14

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 16.98 % 18.07 % 1.6 px 1.7 px
3 pixels 11.97 % 12.80 % 1.6 px 1.7 px
4 pixels 9.53 % 10.38 % 1.6 px 1.7 px
5 pixels 7.75 % 8.56 % 1.6 px 1.7 px
This table as LaTeX





Test Image 15

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 15.10 % 15.81 % 1.4 px 1.5 px
3 pixels 8.65 % 9.16 % 1.4 px 1.5 px
4 pixels 6.03 % 6.56 % 1.4 px 1.5 px
5 pixels 4.64 % 5.17 % 1.4 px 1.5 px
This table as LaTeX





Test Image 16

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 15.50 % 15.80 % 1.1 px 1.1 px
3 pixels 7.71 % 7.89 % 1.1 px 1.1 px
4 pixels 4.54 % 4.63 % 1.1 px 1.1 px
5 pixels 3.18 % 3.19 % 1.1 px 1.1 px
This table as LaTeX





Test Image 17

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 17.18 % 18.28 % 2.1 px 2.2 px
3 pixels 13.25 % 14.06 % 2.1 px 2.2 px
4 pixels 11.64 % 12.20 % 2.1 px 2.2 px
5 pixels 10.09 % 10.55 % 2.1 px 2.2 px
This table as LaTeX





Test Image 18

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 22.38 % 23.11 % 1.5 px 1.6 px
3 pixels 16.83 % 17.48 % 1.5 px 1.6 px
4 pixels 12.87 % 13.42 % 1.5 px 1.6 px
5 pixels 9.95 % 10.48 % 1.5 px 1.6 px
This table as LaTeX





Test Image 19

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 10.72 % 13.29 % 1.2 px 1.3 px
3 pixels 6.88 % 9.07 % 1.2 px 1.3 px
4 pixels 4.29 % 6.18 % 1.2 px 1.3 px
5 pixels 2.78 % 4.21 % 1.2 px 1.3 px
This table as LaTeX
