Method

Iterative Geometry Encoding Volume for Stereo Matching and Multi-View Stereo [IGEV-Stereo]


Submitted on 25 Jan. 2023 12:48 by
Gangwei Xu (Huazhong University of Science and Technology)

Running time:0.18 s
Environment:NVIDIA RTX 3090 (PyTorch)

Method Description:
Iterative Geometry Encoding Volume for Stereo
Matching and Multi-View Stereo
Parameters:
16 GRUs iterations, lr=2e-4
Latex Bibtex:
@inproceedings{xu2023iterative,
title={Iterative Geometry Encoding Volume for
Stereo Matching},
author={Xu, Gangwei and Wang, Xianqi and Ding,
Xiaohuan and Yang, Xin},
booktitle={CVPR},
pages={21919--21928},
year={2023}
}

Detailed Results

This page provides detailed results for the method(s) selected. For each of the first 20 test images, the number of erroneous pixels at all thresholds is depicted in the table. Underneath, the left input image, the disparity / end-point error map and the estimated (and interpolated) disparity / optical flow map are shown. The error map scales linearly between 0 (black) and >=5 (white) pixels error. Red denotes all occluded pixels, falling outside the image boundaries. The false color map is scaled to the largest ground truth disparity / flow value.

Test Set Average

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.71 % 2.17 % 0.4 px 0.4 px
3 pixels 1.12 % 1.44 % 0.4 px 0.4 px
4 pixels 0.88 % 1.12 % 0.4 px 0.4 px
5 pixels 0.73 % 0.94 % 0.4 px 0.4 px
This table as LaTeX

Reflective Regions

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 7.57 % 8.80 % 1.0 px 1.1 px
3 pixels 4.35 % 5.00 % 1.0 px 1.1 px
4 pixels 3.16 % 3.57 % 1.0 px 1.1 px
5 pixels 2.55 % 2.86 % 1.0 px 1.1 px
This table as LaTeX

Test Image 0

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.15 % 1.37 % 0.4 px 0.4 px
3 pixels 0.92 % 1.15 % 0.4 px 0.4 px
4 pixels 0.82 % 1.05 % 0.4 px 0.4 px
5 pixels 0.76 % 1.00 % 0.4 px 0.4 px
This table as LaTeX





Test Image 1

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 2.53 % 2.53 % 0.5 px 0.5 px
3 pixels 1.75 % 1.72 % 0.5 px 0.5 px
4 pixels 1.43 % 1.42 % 0.5 px 0.5 px
5 pixels 1.18 % 1.18 % 0.5 px 0.5 px
This table as LaTeX





Test Image 2

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.74 % 0.78 % 0.3 px 0.3 px
3 pixels 0.60 % 0.64 % 0.3 px 0.3 px
4 pixels 0.51 % 0.55 % 0.3 px 0.3 px
5 pixels 0.45 % 0.49 % 0.3 px 0.3 px
This table as LaTeX





Test Image 3

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.36 % 0.96 % 0.3 px 0.3 px
3 pixels 0.23 % 0.40 % 0.3 px 0.3 px
4 pixels 0.20 % 0.20 % 0.3 px 0.3 px
5 pixels 0.19 % 0.19 % 0.3 px 0.3 px
This table as LaTeX





Test Image 4

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.63 % 0.77 % 0.3 px 0.3 px
3 pixels 0.24 % 0.33 % 0.3 px 0.3 px
4 pixels 0.18 % 0.24 % 0.3 px 0.3 px
5 pixels 0.13 % 0.19 % 0.3 px 0.3 px
This table as LaTeX





Test Image 5

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.77 % 0.87 % 0.3 px 0.3 px
3 pixels 0.46 % 0.55 % 0.3 px 0.3 px
4 pixels 0.38 % 0.42 % 0.3 px 0.3 px
5 pixels 0.30 % 0.34 % 0.3 px 0.3 px
This table as LaTeX





Test Image 6

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 3.86 % 4.77 % 0.6 px 0.6 px
3 pixels 1.82 % 2.30 % 0.6 px 0.6 px
4 pixels 1.23 % 1.61 % 0.6 px 0.6 px
5 pixels 1.00 % 1.33 % 0.6 px 0.6 px
This table as LaTeX





Test Image 7

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.31 % 1.93 % 0.5 px 0.6 px
3 pixels 0.87 % 1.22 % 0.5 px 0.6 px
4 pixels 0.75 % 1.02 % 0.5 px 0.6 px
5 pixels 0.69 % 0.93 % 0.5 px 0.6 px
This table as LaTeX





Test Image 8

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.05 % 1.48 % 0.3 px 0.3 px
3 pixels 0.72 % 1.10 % 0.3 px 0.3 px
4 pixels 0.60 % 0.97 % 0.3 px 0.3 px
5 pixels 0.49 % 0.65 % 0.3 px 0.3 px
This table as LaTeX





Test Image 9

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.19 % 1.49 % 0.4 px 0.6 px
3 pixels 0.73 % 0.98 % 0.4 px 0.6 px
4 pixels 0.58 % 0.79 % 0.4 px 0.6 px
5 pixels 0.51 % 0.69 % 0.4 px 0.6 px
This table as LaTeX





Test Image 10

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.14 % 1.14 % 0.3 px 0.3 px
3 pixels 0.78 % 0.77 % 0.3 px 0.3 px
4 pixels 0.58 % 0.58 % 0.3 px 0.3 px
5 pixels 0.54 % 0.53 % 0.3 px 0.3 px
This table as LaTeX





Test Image 11

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.21 % 1.24 % 0.4 px 0.4 px
3 pixels 0.70 % 0.69 % 0.4 px 0.4 px
4 pixels 0.51 % 0.49 % 0.4 px 0.4 px
5 pixels 0.42 % 0.40 % 0.4 px 0.4 px
This table as LaTeX





Test Image 12

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.90 % 4.05 % 0.5 px 0.6 px
3 pixels 1.41 % 3.35 % 0.5 px 0.6 px
4 pixels 1.13 % 2.89 % 0.5 px 0.6 px
5 pixels 1.00 % 2.58 % 0.5 px 0.6 px
This table as LaTeX





Test Image 13

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.39 % 1.52 % 0.4 px 0.5 px
3 pixels 1.05 % 1.06 % 0.4 px 0.5 px
4 pixels 0.90 % 0.90 % 0.4 px 0.5 px
5 pixels 0.82 % 0.82 % 0.4 px 0.5 px
This table as LaTeX





Test Image 14

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.23 % 0.91 % 0.2 px 0.3 px
3 pixels 0.18 % 0.84 % 0.2 px 0.3 px
4 pixels 0.16 % 0.80 % 0.2 px 0.3 px
5 pixels 0.12 % 0.50 % 0.2 px 0.3 px
This table as LaTeX





Test Image 15

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 2.40 % 2.42 % 0.4 px 0.4 px
3 pixels 1.56 % 1.53 % 0.4 px 0.4 px
4 pixels 0.97 % 0.95 % 0.4 px 0.4 px
5 pixels 0.49 % 0.47 % 0.4 px 0.4 px
This table as LaTeX





Test Image 16

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.74 % 1.71 % 0.4 px 0.4 px
3 pixels 0.85 % 0.83 % 0.4 px 0.4 px
4 pixels 0.49 % 0.48 % 0.4 px 0.4 px
5 pixels 0.35 % 0.34 % 0.4 px 0.4 px
This table as LaTeX





Test Image 17

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 3.23 % 3.38 % 0.4 px 0.5 px
3 pixels 2.04 % 2.14 % 0.4 px 0.5 px
4 pixels 1.47 % 1.57 % 0.4 px 0.5 px
5 pixels 1.20 % 1.30 % 0.4 px 0.5 px
This table as LaTeX





Test Image 18

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.39 % 0.49 % 0.2 px 0.2 px
3 pixels 0.28 % 0.39 % 0.2 px 0.2 px
4 pixels 0.20 % 0.31 % 0.2 px 0.2 px
5 pixels 0.15 % 0.26 % 0.2 px 0.2 px
This table as LaTeX





Test Image 19

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.92 % 0.89 % 0.4 px 0.4 px
3 pixels 0.64 % 0.62 % 0.4 px 0.4 px
4 pixels 0.54 % 0.53 % 0.4 px 0.4 px
5 pixels 0.48 % 0.46 % 0.4 px 0.4 px
This table as LaTeX
