Dense block-based motion estimation by matching novel 2-bit transforms of Laplacian subbands [2Bit-BM-tele]
http://dstn.ee.unsw.edu.au/~rui/

Submitted on 25 May. 2014 12:18 by
Rui Xu (UNSW)

Running time:6 min
Environment:1 core @ 2.4 Ghz (C/C++)

Method Description:
Block-based motion estimation at each pixel location by matching
in each Laplacian subband after heavy quantization and then
combined.

with a telescopic search strategy
Parameters:
thresholding: L = 6, gain = 1, \delta = 0
morphological dilation: 6 times (\epsilon = 3)
5 resolution levels
block size(matching window): 29X29 (measured locally at each
resolution)
search step = 0.25
search range = 128

Latex Bibtex:
@article{xu-2013,
author = "Xu, R. and Taubman, D.",
title = "Robust Dense Block-Based Motion Estimation Using a
Two-Bit Transform on a Laplacian Pyramid",
journal = "20th Proc. IEEE Int. Conf. Image Proc. 2013",
year = "2013",
month = "September",
note={accepted for publication, available at
\url{http://dstn.ee.unsw.edu.au/~rui/xu-icip2013.pdf}}
}


Rui Xu, David Taubman & Aous Thabit Naman, “Nonlinear
Transform for Robust Dense Block Based Motion Estimation,”
Accepted for publication to Transactions on Image Processing in
March 2014 http://dstn.ee.unsw.edu.au/~rui/xu-
journal2013.pdf

Detailed Results
