Method

Area-based Correlation and Non-local Attention Network for Stereo Matching [Abc-Net]


Submitted on 19 Oct. 2020 10:03 by
Li Xing (Northwestern Polytechnical University)

Running time:0.72 s
Environment:4 cores @ 2.5 Ghz (Python)

Method Description:
Area-based Correlation and Non-local Attention
Network for Stereo Matching
Parameters:
learning rate=0.001
Latex Bibtex:
@article{li2021area,
title={Area-based correlation and non-local
attention network for stereo matching},
author={Li, Xing and Fan, Yangyu and Lv, Guoyun
and Ma, Haoyue},
journal={The Visual Computer},
pages={1--15},
year={2021},
publisher={Springer}
}

Detailed Results

This page provides detailed results for the method(s) selected. For each of the first 20 test images, the number of erroneous pixels at all thresholds is depicted in the table. Underneath, the left input image, the disparity / end-point error map and the estimated (and interpolated) disparity / optical flow map are shown. The error map scales linearly between 0 (black) and >=5 (white) pixels error. Red denotes all occluded pixels, falling outside the image boundaries. The false color map is scaled to the largest ground truth disparity / flow value.

Test Set Average

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.91 % 2.51 % 0.4 px 0.5 px
3 pixels 1.18 % 1.59 % 0.4 px 0.5 px
4 pixels 0.88 % 1.20 % 0.4 px 0.5 px
5 pixels 0.72 % 0.97 % 0.4 px 0.5 px
This table as LaTeX

Reflective Regions

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 11.66 % 13.79 % 1.4 px 1.5 px
3 pixels 6.80 % 8.40 % 1.4 px 1.5 px
4 pixels 4.73 % 5.92 % 1.4 px 1.5 px
5 pixels 3.63 % 4.52 % 1.4 px 1.5 px
This table as LaTeX

Test Image 0

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.12 % 1.61 % 0.4 px 0.4 px
3 pixels 0.70 % 1.11 % 0.4 px 0.4 px
4 pixels 0.53 % 0.85 % 0.4 px 0.4 px
5 pixels 0.45 % 0.74 % 0.4 px 0.4 px
This table as LaTeX





Test Image 1

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 2.26 % 3.18 % 0.5 px 0.5 px
3 pixels 1.44 % 1.70 % 0.5 px 0.5 px
4 pixels 1.10 % 1.32 % 0.5 px 0.5 px
5 pixels 0.97 % 1.13 % 0.5 px 0.5 px
This table as LaTeX





Test Image 2

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.09 % 1.46 % 0.3 px 0.3 px
3 pixels 0.57 % 0.66 % 0.3 px 0.3 px
4 pixels 0.41 % 0.45 % 0.3 px 0.3 px
5 pixels 0.36 % 0.40 % 0.3 px 0.3 px
This table as LaTeX





Test Image 3

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.48 % 0.53 % 0.3 px 0.3 px
3 pixels 0.24 % 0.24 % 0.3 px 0.3 px
4 pixels 0.18 % 0.18 % 0.3 px 0.3 px
5 pixels 0.15 % 0.14 % 0.3 px 0.3 px
This table as LaTeX





Test Image 4

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.27 % 1.48 % 0.3 px 0.4 px
3 pixels 0.95 % 1.04 % 0.3 px 0.4 px
4 pixels 0.64 % 0.69 % 0.3 px 0.4 px
5 pixels 0.16 % 0.20 % 0.3 px 0.4 px
This table as LaTeX





Test Image 5

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.74 % 0.80 % 0.3 px 0.3 px
3 pixels 0.48 % 0.51 % 0.3 px 0.3 px
4 pixels 0.33 % 0.34 % 0.3 px 0.3 px
5 pixels 0.28 % 0.27 % 0.3 px 0.3 px
This table as LaTeX





Test Image 6

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 3.61 % 4.08 % 0.5 px 0.6 px
3 pixels 1.68 % 1.97 % 0.5 px 0.6 px
4 pixels 1.03 % 1.19 % 0.5 px 0.6 px
5 pixels 0.79 % 0.88 % 0.5 px 0.6 px
This table as LaTeX





Test Image 7

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 2.10 % 3.05 % 0.6 px 0.7 px
3 pixels 1.20 % 1.88 % 0.6 px 0.7 px
4 pixels 0.92 % 1.54 % 0.6 px 0.7 px
5 pixels 0.79 % 1.36 % 0.6 px 0.7 px
This table as LaTeX





Test Image 8

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.18 % 1.64 % 0.3 px 0.4 px
3 pixels 0.75 % 1.21 % 0.3 px 0.4 px
4 pixels 0.66 % 1.12 % 0.3 px 0.4 px
5 pixels 0.60 % 1.04 % 0.3 px 0.4 px
This table as LaTeX





Test Image 9

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 2.35 % 4.34 % 0.6 px 0.8 px
3 pixels 1.42 % 3.10 % 0.6 px 0.8 px
4 pixels 1.07 % 2.42 % 0.6 px 0.8 px
5 pixels 0.93 % 1.63 % 0.6 px 0.8 px
This table as LaTeX





Test Image 10

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.96 % 1.54 % 0.3 px 0.4 px
3 pixels 0.59 % 0.82 % 0.3 px 0.4 px
4 pixels 0.43 % 0.50 % 0.3 px 0.4 px
5 pixels 0.39 % 0.43 % 0.3 px 0.4 px
This table as LaTeX





Test Image 11

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.32 % 1.55 % 0.5 px 0.5 px
3 pixels 0.83 % 0.96 % 0.5 px 0.5 px
4 pixels 0.64 % 0.70 % 0.5 px 0.5 px
5 pixels 0.54 % 0.56 % 0.5 px 0.5 px
This table as LaTeX





Test Image 12

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 2.54 % 4.71 % 0.5 px 0.7 px
3 pixels 1.68 % 3.63 % 0.5 px 0.7 px
4 pixels 1.36 % 3.16 % 0.5 px 0.7 px
5 pixels 1.24 % 2.81 % 0.5 px 0.7 px
This table as LaTeX





Test Image 13

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.51 % 2.20 % 0.5 px 0.5 px
3 pixels 0.86 % 1.45 % 0.5 px 0.5 px
4 pixels 0.72 % 1.22 % 0.5 px 0.5 px
5 pixels 0.66 % 1.07 % 0.5 px 0.5 px
This table as LaTeX





Test Image 14

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.49 % 0.48 % 0.3 px 0.3 px
3 pixels 0.28 % 0.27 % 0.3 px 0.3 px
4 pixels 0.21 % 0.20 % 0.3 px 0.3 px
5 pixels 0.19 % 0.19 % 0.3 px 0.3 px
This table as LaTeX





Test Image 15

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 2.44 % 2.60 % 0.5 px 0.5 px
3 pixels 1.38 % 1.35 % 0.5 px 0.5 px
4 pixels 0.70 % 0.68 % 0.5 px 0.5 px
5 pixels 0.54 % 0.53 % 0.5 px 0.5 px
This table as LaTeX





Test Image 16

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 1.88 % 1.85 % 0.4 px 0.4 px
3 pixels 0.92 % 0.91 % 0.4 px 0.4 px
4 pixels 0.57 % 0.56 % 0.4 px 0.4 px
5 pixels 0.39 % 0.38 % 0.4 px 0.4 px
This table as LaTeX





Test Image 17

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 3.01 % 4.29 % 0.5 px 0.6 px
3 pixels 2.07 % 3.16 % 0.5 px 0.6 px
4 pixels 1.68 % 2.05 % 0.5 px 0.6 px
5 pixels 1.18 % 1.37 % 0.5 px 0.6 px
This table as LaTeX





Test Image 18

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.45 % 0.63 % 0.3 px 0.3 px
3 pixels 0.31 % 0.35 % 0.3 px 0.3 px
4 pixels 0.24 % 0.24 % 0.3 px 0.3 px
5 pixels 0.18 % 0.17 % 0.3 px 0.3 px
This table as LaTeX





Test Image 19

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 0.90 % 0.88 % 0.4 px 0.4 px
3 pixels 0.66 % 0.64 % 0.4 px 0.4 px
4 pixels 0.58 % 0.56 % 0.4 px 0.4 px
5 pixels 0.50 % 0.48 % 0.4 px 0.4 px
This table as LaTeX
