Method

LogN - SymStereo on GPU [SymST-GP]


Submitted on 10 Apr. 2015 18:03 by
Ricardo Ralha (Instituto de Telecomunicações)

Running time:0.254 s
Environment:Dual - Nvidia GTX Titan (CUDA)

Method Description:
Real-time stereo pipeline using a symmetry-based
dense stereo algorithm and post processing
techniques to fill the pixels in the occluded
regions.
Parameters:
- Number of scales of the log-Gabor filters
- Shape factor
- Scaling step
- Center frequency of the mother wavelet
- Aggregation window
- Left–right consistency threshold
Latex Bibtex:
@Article{Ralha2016,
author="Ralha, Ricardo
and Falcao, Gabriel
and Amaro, Joao
and Mota, Vasco
and Antunes, Michel
and Barreto, Joao
and Nunes, Urbano",
title="Parallel refinement of slanted 3D
reconstruction using dense stereo induced from
symmetry",
journal="Journal of Real-Time Image
Processing",
year="2016",
pages="1--19",
issn="1861-8219",
doi="10.1007/s11554-016-0592-0",
url="http://dx.doi.org/10.1007/s11554-016-0592-
0"
}

Detailed Results

This page provides detailed results for the method(s) selected. For each of the first 20 test images, the number of erroneous pixels at all thresholds is depicted in the table. Underneath, the left input image, the disparity / end-point error map and the estimated (and interpolated) disparity / optical flow map are shown. The error map scales linearly between 0 (black) and >=5 (white) pixels error. Red denotes all occluded pixels, falling outside the image boundaries. The false color map is scaled to the largest ground truth disparity / flow value.

Test Set Average

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 12.94 % 14.84 % 2.5 px 3.3 px
3 pixels 9.79 % 11.66 % 2.5 px 3.3 px
4 pixels 8.43 % 10.25 % 2.5 px 3.3 px
5 pixels 7.57 % 9.34 % 2.5 px 3.3 px
This table as LaTeX

Reflective Regions

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 39.69 % 42.98 % 12.1 px 15.2 px
3 pixels 33.68 % 37.24 % 12.1 px 15.2 px
4 pixels 30.18 % 33.86 % 12.1 px 15.2 px
5 pixels 27.81 % 31.58 % 12.1 px 15.2 px
This table as LaTeX

Test Image 0

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 10.85 % 13.31 % 1.6 px 2.0 px
3 pixels 7.96 % 10.29 % 1.6 px 2.0 px
4 pixels 6.65 % 8.82 % 1.6 px 2.0 px
5 pixels 5.48 % 7.47 % 1.6 px 2.0 px
This table as LaTeX





Test Image 1

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 9.89 % 13.50 % 1.3 px 2.1 px
3 pixels 6.58 % 10.27 % 1.3 px 2.1 px
4 pixels 5.10 % 8.57 % 1.3 px 2.1 px
5 pixels 4.32 % 7.55 % 1.3 px 2.1 px
This table as LaTeX





Test Image 2

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 15.56 % 16.76 % 2.8 px 3.2 px
3 pixels 12.25 % 13.31 % 2.8 px 3.2 px
4 pixels 10.43 % 11.50 % 2.8 px 3.2 px
5 pixels 9.05 % 10.15 % 2.8 px 3.2 px
This table as LaTeX





Test Image 3

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.29 % 15.69 % 1.9 px 3.0 px
3 pixels 8.38 % 10.72 % 1.9 px 3.0 px
4 pixels 6.89 % 8.95 % 1.9 px 3.0 px
5 pixels 6.21 % 7.97 % 1.9 px 3.0 px
This table as LaTeX





Test Image 4

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.21 % 15.00 % 2.2 px 2.7 px
3 pixels 9.18 % 10.77 % 2.2 px 2.7 px
4 pixels 7.86 % 9.32 % 2.2 px 2.7 px
5 pixels 6.92 % 8.37 % 2.2 px 2.7 px
This table as LaTeX





Test Image 5

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 5.28 % 6.46 % 1.3 px 1.6 px
3 pixels 3.79 % 4.87 % 1.3 px 1.6 px
4 pixels 3.36 % 4.39 % 1.3 px 1.6 px
5 pixels 3.07 % 4.08 % 1.3 px 1.6 px
This table as LaTeX





Test Image 6

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 15.25 % 17.52 % 3.0 px 3.9 px
3 pixels 11.23 % 13.50 % 3.0 px 3.9 px
4 pixels 9.64 % 11.90 % 3.0 px 3.9 px
5 pixels 8.81 % 11.05 % 3.0 px 3.9 px
This table as LaTeX





Test Image 7

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 22.41 % 24.35 % 3.8 px 5.1 px
3 pixels 16.84 % 18.91 % 3.8 px 5.1 px
4 pixels 14.10 % 16.23 % 3.8 px 5.1 px
5 pixels 12.70 % 14.87 % 3.8 px 5.1 px
This table as LaTeX





Test Image 8

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 4.80 % 6.49 % 0.9 px 1.3 px
3 pixels 3.09 % 4.61 % 0.9 px 1.3 px
4 pixels 2.26 % 3.70 % 0.9 px 1.3 px
5 pixels 1.87 % 3.24 % 0.9 px 1.3 px
This table as LaTeX





Test Image 9

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 18.89 % 20.90 % 3.6 px 4.3 px
3 pixels 14.26 % 16.38 % 3.6 px 4.3 px
4 pixels 12.06 % 14.23 % 3.6 px 4.3 px
5 pixels 10.85 % 13.05 % 3.6 px 4.3 px
This table as LaTeX





Test Image 10

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 8.12 % 9.75 % 1.6 px 2.4 px
3 pixels 5.25 % 6.93 % 1.6 px 2.4 px
4 pixels 4.21 % 5.90 % 1.6 px 2.4 px
5 pixels 3.65 % 5.35 % 1.6 px 2.4 px
This table as LaTeX





Test Image 11

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 21.70 % 24.59 % 3.8 px 5.0 px
3 pixels 15.34 % 18.38 % 3.8 px 5.0 px
4 pixels 12.57 % 15.65 % 3.8 px 5.0 px
5 pixels 11.13 % 14.18 % 3.8 px 5.0 px
This table as LaTeX





Test Image 12

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 12.13 % 14.40 % 2.3 px 4.6 px
3 pixels 9.24 % 11.58 % 2.3 px 4.6 px
4 pixels 8.11 % 10.48 % 2.3 px 4.6 px
5 pixels 7.52 % 9.91 % 2.3 px 4.6 px
This table as LaTeX





Test Image 13

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 15.61 % 16.78 % 2.7 px 3.7 px
3 pixels 12.17 % 13.39 % 2.7 px 3.7 px
4 pixels 10.85 % 12.08 % 2.7 px 3.7 px
5 pixels 9.84 % 11.08 % 2.7 px 3.7 px
This table as LaTeX





Test Image 14

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 14.44 % 16.33 % 3.3 px 4.0 px
3 pixels 11.43 % 13.30 % 3.3 px 4.0 px
4 pixels 10.05 % 11.92 % 3.3 px 4.0 px
5 pixels 9.17 % 11.05 % 3.3 px 4.0 px
This table as LaTeX





Test Image 15

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 11.28 % 12.50 % 1.6 px 1.8 px
3 pixels 7.15 % 8.17 % 1.6 px 1.8 px
4 pixels 5.35 % 6.33 % 1.6 px 1.8 px
5 pixels 4.35 % 5.29 % 1.6 px 1.8 px
This table as LaTeX





Test Image 16

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 9.26 % 10.77 % 1.5 px 1.9 px
3 pixels 5.71 % 7.25 % 1.5 px 1.9 px
4 pixels 4.37 % 5.94 % 1.5 px 1.9 px
5 pixels 3.66 % 5.23 % 1.5 px 1.9 px
This table as LaTeX





Test Image 17

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 10.88 % 12.53 % 1.9 px 2.3 px
3 pixels 8.83 % 10.35 % 1.9 px 2.3 px
4 pixels 7.61 % 8.86 % 1.9 px 2.3 px
5 pixels 6.56 % 7.59 % 1.9 px 2.3 px
This table as LaTeX





Test Image 18

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 12.19 % 13.19 % 1.5 px 1.8 px
3 pixels 9.61 % 10.57 % 1.5 px 1.8 px
4 pixels 8.44 % 9.38 % 1.5 px 1.8 px
5 pixels 7.37 % 8.29 % 1.5 px 1.8 px
This table as LaTeX





Test Image 19

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 8.90 % 11.36 % 2.6 px 3.2 px
3 pixels 6.77 % 9.16 % 2.6 px 3.2 px
4 pixels 6.20 % 8.52 % 2.6 px 3.2 px
5 pixels 5.86 % 8.11 % 2.6 px 3.2 px
This table as LaTeX
