Efficient Methods Using Slanted Support Windows for Slanted Surfaces [SSMW]


Submitted on 7 Apr. 2016 05:07 by
Benz Lee (WHUT)

Running time:2.5 min
Environment:8 cores @ 2.5 Ghz (C/C++)

Method Description:
The frontal-parallel assumption is made by many
matching algorithms, but this assumption fails
for slanted surfaces. This paper proposes a
matching algorithm intended to improve the
matching results for slanted surfaces. First, a
mathematical model is constructed to prove that
slanted surfaces in the environment have
corresponding slanted disparity surfaces in the
disparity space image (DSI), and the model is
to help find the proper plane parameters of
slanted support windows. Then, improved cost
aggregation and post-processing methods are
proposed.
Parameters:
D = 10, S = 4, window size = 51.
Latex Bibtex:
@INPROCEEDINGS{IET Computer Vision,
author = {Xuesong Li and Jianguo Liu and Guang
Chen and Heng Fu},
title = {Efficient Methods Using Slanted
Support Windows for Slanted Surfaces},
booktitle = {IET Computer Vision,
http://ietdl.org/t/5QsTxb},
year = {2016}
}

Detailed Results

This page provides detailed results for the method(s) selected. For each of the first 20 test images, the number of erroneous pixels at all thresholds is depicted in the table. Underneath, the left input image, the disparity / end-point error map and the estimated (and interpolated) disparity / optical flow map are shown. The error map scales linearly between 0 (black) and >=5 (white) pixels error. Red denotes all occluded pixels, falling outside the image boundaries. The false color map is scaled to the largest ground truth disparity / flow value.

Test Set Average

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 10.83 % 12.22 % 1.6 px 1.8 px
3 pixels 7.83 % 8.95 % 1.6 px 1.8 px
4 pixels 6.31 % 7.22 % 1.6 px 1.8 px
5 pixels 5.33 % 6.12 % 1.6 px 1.8 px
This table as LaTeX

Reflective Regions

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 35.24 % 38.27 % 5.2 px 6.2 px
3 pixels 27.84 % 30.96 % 5.2 px 6.2 px
4 pixels 23.53 % 26.59 % 5.2 px 6.2 px
5 pixels 20.59 % 23.54 % 5.2 px 6.2 px
This table as LaTeX

Test Image 0

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 8.05 % 9.93 % 1.0 px 1.1 px
3 pixels 5.21 % 6.60 % 1.0 px 1.1 px
4 pixels 3.66 % 4.64 % 1.0 px 1.1 px
5 pixels 2.54 % 3.39 % 1.0 px 1.1 px
This table as LaTeX





Test Image 1

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 9.35 % 12.44 % 1.1 px 1.3 px
3 pixels 6.43 % 8.91 % 1.1 px 1.3 px
4 pixels 5.17 % 6.82 % 1.1 px 1.3 px
5 pixels 4.38 % 5.38 % 1.1 px 1.3 px
This table as LaTeX





Test Image 2

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 12.59 % 13.72 % 1.7 px 1.7 px
3 pixels 8.82 % 9.40 % 1.7 px 1.7 px
4 pixels 7.06 % 7.39 % 1.7 px 1.7 px
5 pixels 6.09 % 6.36 % 1.7 px 1.7 px
This table as LaTeX





Test Image 3

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 25.95 % 27.59 % 2.4 px 2.5 px
3 pixels 20.61 % 21.93 % 2.4 px 2.5 px
4 pixels 17.03 % 17.99 % 2.4 px 2.5 px
5 pixels 14.34 % 15.10 % 2.4 px 2.5 px
This table as LaTeX





Test Image 4

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 8.81 % 10.37 % 1.3 px 1.5 px
3 pixels 6.16 % 7.29 % 1.3 px 1.5 px
4 pixels 4.76 % 5.49 % 1.3 px 1.5 px
5 pixels 4.27 % 4.83 % 1.3 px 1.5 px
This table as LaTeX





Test Image 5

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 5.00 % 5.23 % 1.0 px 1.0 px
3 pixels 3.70 % 3.79 % 1.0 px 1.0 px
4 pixels 3.24 % 3.32 % 1.0 px 1.0 px
5 pixels 2.90 % 2.98 % 1.0 px 1.0 px
This table as LaTeX





Test Image 6

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 20.31 % 20.92 % 4.0 px 4.2 px
3 pixels 15.69 % 16.40 % 4.0 px 4.2 px
4 pixels 14.10 % 14.84 % 4.0 px 4.2 px
5 pixels 12.99 % 13.76 % 4.0 px 4.2 px
This table as LaTeX





Test Image 7

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 12.89 % 14.53 % 1.7 px 2.0 px
3 pixels 8.26 % 9.91 % 1.7 px 2.0 px
4 pixels 6.41 % 7.97 % 1.7 px 2.0 px
5 pixels 5.41 % 6.83 % 1.7 px 2.0 px
This table as LaTeX





Test Image 8

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 6.40 % 7.32 % 1.2 px 1.2 px
3 pixels 4.61 % 5.06 % 1.2 px 1.2 px
4 pixels 3.85 % 4.25 % 1.2 px 1.2 px
5 pixels 3.38 % 3.80 % 1.2 px 1.2 px
This table as LaTeX





Test Image 9

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 17.98 % 20.00 % 2.3 px 2.7 px
3 pixels 10.92 % 13.09 % 2.3 px 2.7 px
4 pixels 8.17 % 10.40 % 2.3 px 2.7 px
5 pixels 7.20 % 9.42 % 2.3 px 2.7 px
This table as LaTeX





Test Image 10

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.08 % 14.22 % 4.1 px 4.1 px
3 pixels 11.17 % 12.21 % 4.1 px 4.1 px
4 pixels 10.14 % 11.02 % 4.1 px 4.1 px
5 pixels 9.40 % 10.08 % 4.1 px 4.1 px
This table as LaTeX





Test Image 11

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 18.57 % 21.16 % 2.2 px 2.2 px
3 pixels 12.17 % 13.76 % 2.2 px 2.2 px
4 pixels 9.07 % 9.59 % 2.2 px 2.2 px
5 pixels 7.25 % 7.27 % 2.2 px 2.2 px
This table as LaTeX





Test Image 12

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 14.13 % 16.34 % 2.7 px 4.5 px
3 pixels 11.42 % 13.71 % 2.7 px 4.5 px
4 pixels 9.71 % 12.04 % 2.7 px 4.5 px
5 pixels 8.70 % 11.06 % 2.7 px 4.5 px
This table as LaTeX





Test Image 13

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.25 % 14.20 % 2.0 px 2.2 px
3 pixels 10.35 % 11.21 % 2.0 px 2.2 px
4 pixels 8.73 % 9.47 % 2.0 px 2.2 px
5 pixels 7.44 % 8.13 % 2.0 px 2.2 px
This table as LaTeX





Test Image 14

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 10.01 % 11.22 % 1.0 px 1.0 px
3 pixels 6.49 % 7.51 % 1.0 px 1.0 px
4 pixels 4.35 % 4.97 % 1.0 px 1.0 px
5 pixels 3.25 % 3.60 % 1.0 px 1.0 px
This table as LaTeX





Test Image 15

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 17.62 % 18.95 % 1.8 px 1.9 px
3 pixels 14.12 % 14.90 % 1.8 px 1.9 px
4 pixels 11.51 % 12.15 % 1.8 px 1.9 px
5 pixels 9.55 % 10.13 % 1.8 px 1.9 px
This table as LaTeX





Test Image 16

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 8.76 % 8.76 % 1.1 px 1.1 px
3 pixels 5.40 % 5.36 % 1.1 px 1.1 px
4 pixels 3.90 % 3.87 % 1.1 px 1.1 px
5 pixels 3.01 % 3.00 % 1.1 px 1.1 px
This table as LaTeX





Test Image 17

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 9.45 % 10.32 % 1.2 px 1.3 px
3 pixels 7.18 % 7.74 % 1.2 px 1.3 px
4 pixels 5.61 % 5.90 % 1.2 px 1.3 px
5 pixels 4.34 % 4.53 % 1.2 px 1.3 px
This table as LaTeX





Test Image 18

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 9.14 % 9.87 % 1.1 px 1.1 px
3 pixels 7.17 % 7.81 % 1.1 px 1.1 px
4 pixels 5.93 % 6.50 % 1.1 px 1.1 px
5 pixels 5.10 % 5.57 % 1.1 px 1.1 px
This table as LaTeX





Test Image 19

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 6.15 % 7.79 % 1.0 px 1.1 px
3 pixels 4.46 % 5.46 % 1.0 px 1.1 px
4 pixels 3.50 % 4.26 % 1.0 px 1.1 px
5 pixels 2.87 % 3.53 % 1.0 px 1.1 px
This table as LaTeX
