Method

Sub-volume filter with occlusion handling [SVFilterOh]


Submitted on 1 Aug. 2016 06:13 by
Mohamed Helala (University of Ontario Institute of Technology)

Running time:2 s
Environment:1 core @ 3 Ghz (C/C++), 1 GTX 780 GPU

Method Description:
Parameters:
Two frame method.
Latex Bibtex:
@InProceedings{17-crv-c-opticalflow,
author = {M.A. Helala and F.Z. Qureshi},
title = {Fast Estimation of Large Displacement Optical Flow
Using Dominant Motion Patterns & Sub-Volume PatchMatch
Filtering},
booktitle = {Proc. 14th Conference on Computer and Robot Vision
(CRV 17)},
year = {2017},
month = {May},
address = {Edmonton},
pages = {8pp},
note = {Best Computer Vision Paper}
}

Detailed Results

This page provides detailed results for the method(s) selected. For each of the first 20 test images, the number of erroneous pixels at all thresholds is depicted in the table. Underneath, the left input image, the disparity / end-point error map and the estimated (and interpolated) disparity / optical flow map are shown. The error map scales linearly between 0 (black) and >=5 (white) pixels error. Red denotes all occluded pixels, falling outside the image boundaries. The false color map is scaled to the largest ground truth disparity / flow value.

Test Set Average

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 26.77 % 36.02 % 4.3 px 9.1 px
3 pixels 20.38 % 30.38 % 4.3 px 9.1 px
4 pixels 16.96 % 27.18 % 4.3 px 9.1 px
5 pixels 14.76 % 24.92 % 4.3 px 9.1 px
This table as LaTeX

Reflective Regions

This table as LaTeX

Test Image 0

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 22.85 % 34.27 % 2.7 px 6.7 px
3 pixels 17.57 % 29.74 % 2.7 px 6.7 px
4 pixels 14.34 % 26.55 % 2.7 px 6.7 px
5 pixels 11.68 % 23.70 % 2.7 px 6.7 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 1

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 15.51 % 27.22 % 1.5 px 3.1 px
3 pixels 9.56 % 21.76 % 1.5 px 3.1 px
4 pixels 6.31 % 18.59 % 1.5 px 3.1 px
5 pixels 4.53 % 16.32 % 1.5 px 3.1 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 2

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 26.68 % 38.31 % 3.0 px 6.9 px
3 pixels 19.56 % 32.26 % 3.0 px 6.9 px
4 pixels 15.96 % 29.05 % 3.0 px 6.9 px
5 pixels 13.43 % 26.68 % 3.0 px 6.9 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 3

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 37.21 % 47.61 % 4.3 px 8.6 px
3 pixels 29.20 % 40.83 % 4.3 px 8.6 px
4 pixels 24.35 % 36.64 % 4.3 px 8.6 px
5 pixels 20.74 % 33.34 % 4.3 px 8.6 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 4

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 13.23 % 20.34 % 1.2 px 1.7 px
3 pixels 7.77 % 14.34 % 1.2 px 1.7 px
4 pixels 4.98 % 10.89 % 1.2 px 1.7 px
5 pixels 3.10 % 8.24 % 1.2 px 1.7 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 5

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 33.09 % 43.73 % 6.2 px 13.8 px
3 pixels 25.28 % 37.13 % 6.2 px 13.8 px
4 pixels 21.40 % 33.82 % 6.2 px 13.8 px
5 pixels 18.97 % 31.72 % 6.2 px 13.8 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 6

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 18.52 % 29.39 % 1.7 px 3.8 px
3 pixels 12.37 % 23.87 % 1.7 px 3.8 px
4 pixels 9.26 % 20.72 % 1.7 px 3.8 px
5 pixels 7.24 % 18.43 % 1.7 px 3.8 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 7

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 32.02 % 43.24 % 4.0 px 10.2 px
3 pixels 23.40 % 35.85 % 4.0 px 10.2 px
4 pixels 18.93 % 31.91 % 4.0 px 10.2 px
5 pixels 15.71 % 28.95 % 4.0 px 10.2 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 8

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 31.51 % 43.79 % 6.2 px 15.7 px
3 pixels 22.83 % 36.63 % 6.2 px 15.7 px
4 pixels 18.75 % 33.20 % 6.2 px 15.7 px
5 pixels 16.16 % 30.98 % 6.2 px 15.7 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 9

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 31.83 % 42.40 % 3.6 px 8.3 px
3 pixels 24.29 % 36.01 % 3.6 px 8.3 px
4 pixels 19.17 % 31.51 % 3.6 px 8.3 px
5 pixels 15.24 % 27.66 % 3.6 px 8.3 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 10

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 31.51 % 43.52 % 5.3 px 15.3 px
3 pixels 24.44 % 37.59 % 5.3 px 15.3 px
4 pixels 20.46 % 34.18 % 5.3 px 15.3 px
5 pixels 18.08 % 32.16 % 5.3 px 15.3 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 11

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 21.79 % 33.94 % 2.2 px 6.0 px
3 pixels 13.23 % 26.34 % 2.2 px 6.0 px
4 pixels 8.99 % 22.12 % 2.2 px 6.0 px
5 pixels 6.87 % 19.45 % 2.2 px 6.0 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 12

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 29.60 % 40.76 % 3.4 px 8.3 px
3 pixels 21.33 % 33.81 % 3.4 px 8.3 px
4 pixels 17.35 % 30.42 % 3.4 px 8.3 px
5 pixels 14.75 % 27.98 % 3.4 px 8.3 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 13

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 25.18 % 34.24 % 3.2 px 8.3 px
3 pixels 19.50 % 29.26 % 3.2 px 8.3 px
4 pixels 16.67 % 26.76 % 3.2 px 8.3 px
5 pixels 14.61 % 24.86 % 3.2 px 8.3 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 14

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 45.98 % 55.17 % 8.2 px 15.6 px
3 pixels 37.14 % 47.83 % 8.2 px 15.6 px
4 pixels 31.92 % 43.50 % 8.2 px 15.6 px
5 pixels 28.54 % 40.70 % 8.2 px 15.6 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 15

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 45.74 % 55.22 % 5.2 px 12.5 px
3 pixels 35.49 % 46.77 % 5.2 px 12.5 px
4 pixels 29.28 % 41.51 % 5.2 px 12.5 px
5 pixels 25.27 % 37.96 % 5.2 px 12.5 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 16

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 5.61 % 15.08 % 0.8 px 2.2 px
3 pixels 2.18 % 10.78 % 0.8 px 2.2 px
4 pixels 1.30 % 8.60 % 0.8 px 2.2 px
5 pixels 0.83 % 7.43 % 0.8 px 2.2 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 17

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 27.54 % 38.81 % 2.3 px 7.5 px
3 pixels 18.42 % 31.02 % 2.3 px 7.5 px
4 pixels 13.86 % 26.97 % 2.3 px 7.5 px
5 pixels 10.75 % 24.03 % 2.3 px 7.5 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 18

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 12.13 % 21.19 % 2.1 px 4.5 px
3 pixels 8.95 % 18.02 % 2.1 px 4.5 px
4 pixels 7.66 % 16.04 % 2.1 px 4.5 px
5 pixels 6.95 % 14.69 % 2.1 px 4.5 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot



Test Image 19

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 12.25 % 22.49 % 1.4 px 3.2 px
3 pixels 8.33 % 18.78 % 1.4 px 3.2 px
4 pixels 6.15 % 16.50 % 1.4 px 3.2 px
5 pixels 4.90 % 14.57 % 1.4 px 3.2 px
This table as LaTeX





This figure as: png eps pdf txt gnuplot
