Two-Frame Motion Estimation Based on Polynomial Expansion [PolyExpand]


Submitted on 26 May. 2012 19:06 by
Andreas Geiger (MPI Tübingen)

Running time:1 s
Environment:1 core @ 2.5 Ghz (C/C++)

Method Description:
Two-frame motion estimation algorithm. The first step is to approximate each neighborhood of both frames by quadratic polynomials, which can be done efficiently using the polynomial expansion transform. From observing how an exact polynomial transforms under translation a method to estimate displacement fields from the polynomial expansion coefficients is derived and after a series of refinements leads to a robust algorithm.

The OpenCV implementation has been used.
Parameters:
pyr_scale = 0.5
levels = 10
winsize = 11
iterations = 20
poly_n = 5
poly_sigma = 1.0
Latex Bibtex:
@InProceedings{Farneback03,
author = {Gunnar Farneback},
title = {Two-Frame Motion Estimation Based on Polynomial Expansion},
booktitle = {SCIA},
pages = {363--370},
year = {2003},
series = {{LNCS} 2749},
address = {Gothenburg, Sweden},
month = {June-July}
}

Detailed Results

This page provides detailed results for the method(s) selected. For each of the first 20 test images, the number of erroneous pixels at all thresholds is depicted in the table. Underneath, the left input image, the disparity / end-point error map and the estimated (and interpolated) disparity / optical flow map are shown. The error map scales linearly between 0 (black) and >=5 (white) pixels error. Red denotes all occluded pixels, falling outside the image boundaries. The false color map is scaled to the largest ground truth disparity / flow value.

Test Set Average

Error Out-Noc Out-All Avg-Noc Avg-All
2 pixels 50.20 % 56.43 % 17.3 px 25.3 px
3 pixels 47.59 % 54.00 % 17.3 px 25.3 px
4 pixels 45.93 % 52.39 % 17.3 px 25.3 px
5 pixels 44.58 % 51.07 % 17.3 px 25.3 px
